CWWK Mini PC Fanless Industrial i7-7500U, 2x RS232/RS485 COM, 2 x Gigabit LAN, Micro Embedded Computer Box, DDR4 32GB RAM 1TB NVMe SSD, SIM, SATA, Mini-PCIe, HD, VGA, 6USB

Marchio: CWWK
Sistema operativo: Win-OS Trial version, license not included
Modello CPU: Core i7 7500U
Velocità CPU: 2,7 GHz
Dimensioni cache: 4 MB
Descrizione scheda grafica: Integrato
Capacità della memoria: 32 GB
Usi specifici del prodotto: Istruzione, Lavoro
Tipo di design del personal computer: Mini PC
Dimensioni memoria RAM: 32 GB

- [i7-7500U & OS Flexibility] Powered by a 7th Gen i7-7500U (2C/4T, up to 3.50GHz, 4MB Cache) balancing processing power and fanless thermal design for heavy SCADA control. SSD variants come pre-loaded with Win11 Pro (Unactivated, for out-of-the-box testing). Fully supports Legacy Boot (CSM) and UEFI, running custom Win10/11 LTSC, Win-Embedded IoT, and Linux
- [Dual LAN & Dual COM Serial] Equipped with 2x RTL8111H Gigabit LAN, supporting Link Aggregation and Network Isolation. Features 2x DB9 COM ports (Default RS232, jumper-configurable to RS485), ideal for PLC, CNC, and field device communication. Supports Auto Power On (AT/ATX jumper-controlled), WOL, PXE, and Hardware WDT for auto-reset, ensuring unattended reliability
- [DDR4 Memory & Versatile I/O] Features 1x SO-DIMM slot supporting up to 32GB 2133MHz DDR4 for heavy industrial multi-tasking. Includes 4x USB 3.0, 2x USB 2.0, and 1x 2x7 Pin TPM 2.0 header. Dual display support via HD1.4 (up to 4K) and VGA. Equipped with a 3.5mm Audio port and a dedicated Clear CMOS jumper for easy maintenance
- [Wireless Network & Flexible Storage] Pre-installed with a WiFi module (antennas included). The Mini-PCIe slot (with SIM slot, supporting PCIe/USB2.0) can alternatively be replaced for 4G/LTE expansion. Features 1x M.2 2280 NVMe/SATA slot and 1x SATA 3.0 port for dual-drive storage (cable included). Supports VESA and rugged embedded wall-mount
- [24/7 Fanless Chassis & Reliability] The fanless rugged chassis ensures silent, dust-proof operation and 24/7 non-stop reliability. Engineered for harsh industrial environments, it supports an extreme operating temperature range of -10 to 60℃. All units undergo rigorous factory testing. We provide an English electronic manual and official technical support from CWWK
